Defining systems to make UI development easier

Believe it or not I play ice hockey for fun in Sydney, Australia. The higher the competitive ladder you climb [in sport] the more common it is to have your coach define and apply systems to the way the team plays, whether you're attacking or defending there are systems in place ready to execute at any given moment! In some ways this is a pretty fitting analogy for software development except we replace the competitive ladder with scale, the coach with an engineering manager or architect, and systems, well, systems still work IMO. When you're a prospect [someone trying to get onto the team] and being scouted the coach will always push for you to "buy into their system" and teams in software development aren't all that different, truly. We all want to be aligned so we can execute with precision and speed.

What systems could we define for UI development?

Boxes and borders

Today most sites use the box sizing property to enable the alternative box model simplifying how we think about the size of an element rendered in the viewport. Set an elements width to 100px and it does exactly what you think it would.

But even with the alternative box model things can still be harder than we'd like them to be. Borders for example are pretty easy to get started with, but use them with multiple elements in different use cases and they start behaving quite nefariously.

Let's go over a few examples with some of these use cases.

.menu-item {

}

Buying in to the [system] means that you love what you are a part of and your joy is infectious to everyone [on the team]._Passion

You might be thinking, "Douges, mate, this is easy! That work around is [fine]…" and honestly? You're not wrong. But let's look at another example first.

.tab-group {

}

More friction and workarounds. We need to think bigger, past a single example and towards how friction can be reduced and how it would work with the entire system.

What if our system applied borders using box shadows?

.menu-item {

}

Well, that's something! Is it perfect in all scenarios? Definitely not. If you're a keen observer you'll notice when we "zoom" into the example [using transform] the box shadow bleeds around the element. It's a tradeoff optimizing for cohesion over perfection throwing away the need to think through multiple moving parts and workarounds.

Interactions and backgrounds

Interactive UI elements like borders are simple to get started. Pick a few different background colors, maybe even a little transform, and you're done. But what would it look like when we're at scale? Let's visualize it.

.button-default {

}

Given enough use cases the need to define all interaction states get pretty wild, and we haven't even touched on UI elements that don't work with backgrounds such as avatars! Each needing decisions to move forward effectively from both design and engineering.

Buying in to the [system] means that you are someone who knows how to stay in the moment._W.I.N

Given the need for varying use cases and enough scale each decision is a vector for friction and potential mistakes. If we were to add a new use case what would the appropriate interaction states be? More decisions!

What if our system had only a single method to add interaction states for any button like element?

.button-brand {
}

Reducing avenues of decisions goes a long way to help reduce friction. When there is only one choice just imagine how fast you can move! The rub though is if there is only one choice it needs to be damn well good.

This missing piece from this abstraction is setting the appropriate color direction [darker or lighter] depending on the background color to ensure it passes accessibility contrast requirements. Getting it correct means the entire system has been built around it, else you end up with friction which we're trying to eliminate.

Margin and layouts

Using margins is simple enough for a single experience, used in a single area of your app. But things get nefarious when that experience now needs to scale to fit other use cases in different areas of your app.

PreviousStart

.thumb {

}

A logical next step could be to move layout concerns to parent elements instead. Thanks to flex box and grid both supporting the gap property in all major browsers it's simple enough to accomplish... but also a bit fiddly by default.

.parent {}

Buying in to the [system] means that you are willing to hold yourself to the standard of what is expected of anyone who [is on the team]._Excellence

At scale we want our team mates to be productive with minimal friction, this includes massaging away behaviour that might have less than ideal defaults.

What if our system had layout abstractions with sensible defaults and baked in design decisions?

<div class="card" />
<div class="card" />
<div class="card" />

Bringing it altogether

These are a few examples of areas we can define in our system that aim to reduce friction and improve cohesion but they aren't exhaustive. Others that are on my mind include accessibility attributes that should be available to all areas of your system, handling layering holistically to avoid z-index fights, and the creation of a button abstraction using a div instead of a button element so they can be nested without it being invalid.

Buying in to the [system] means accepting your role, doing your job, and trusting [leadership] and your teammates._{Team first, team last}

Every gotcha in a system is potential for inaccessible experiences, code workarounds or hacks, and misunderstanding when coming back to the area 6 months from now. What would you define in your system to help alleviate these problems and make your team mates more productive?

Let me know on Twitter what you thought of this blog and if there are any areas you'd be interested to go deeper in. More soon.
